Rancilio Classe 7 USB High Cup

The Rancilio Classe 7 USB High Cup stands out with functionality and ergonomics in an industrial, futuristic design. Featuring the most advanced brewing technologies developed by Rancilio for single boiler espresso machines, it guarantees top thermal stability, accuracy, reliability, and a high level of energy efficiency

Rancilio has been in the espresso machine business since being founded in Parabiago, Italy in 1927.

Espresso Ninja is proud to be the official Rancilio sales and service agent.

Available in two sizes – two group, or three group.

  • LCD display with digital shot timer function
  • Energy-saving Advanced Boiler Management (ABM) function to ensure constant heating temperature levels
  • Automatic stand-by mode to reduce energy consumption while idle
  • Fits tall cups up to 145mm in height, with a retractable tray for using shorter cups
  • Steady Brew patented heat exchanger technology for outstanding temperature consistency
  • Single hot water button with start/stop dosing for full control
  • Barista lights
  • Ergonomic filter holder for comfortable all-day operation
  • Easy-to-use steam valves with quarter-turn steam tap features two positions: purge (down) or fully open (up)
  • Hydro hub – integrated manifold for precise water delivery and distribution
  • Multifunction on-board computer and USB port for simple programming and data transfer
  • Independent water pump and steam pressure control gauges
  • Built-in volumetric rotary vane water pump for simple and safe installation
  • PID steam boiler pressure control
  • An automated cleaning programme simplifies your daily clean
  • Brushed stainless steel front and rear panels
  • Anthracite black ABS nylon side panels
  • Adjustable feet with optional extensions
  • Soft-touch keypads with 4 programmable drink dosing presets for easy espresso preparation
  • White LED backlights easy to read keypad buttons
  • Solid quality and reliability
  • Automatic dose control. Shots can be set to stop automatically after a set volume
  • Wholesale customer? Reach out for wholesale pricing!

Boiler sizes and power requirements:

  • Two group - 11 litre steam boiler - 3750w - 20 amp supply required
  • Three group - 16 litre steam boiler - 6000w - 32 amp supply required

Dimensions and weight:

  • Two group - W: 770mm D: 540mm H: 520mm - 57kg
  • Three group - W: 1010mm D: 540mm H: 520mm- 72kg

Plumbing into mains will require an additional water filtration kit which is site-specific. Contact us to enquire!

Additional information

Choose your size

Two group, Three group
